1
1
Position the left side strip 98B along the
front left side of the upper deck, covering
the edge of the roof panels 97C and 98A.
Note that one end of the strip is slightly
angled at the end – this should be at the
front of the model.
85A
98B
97C
98A
2
2
Fix the strip to the left wall framework 85A
with eight red NM screws. Start from the
rear end of the strip and work forwards, so that
the strip bends to match the shape of the roof.
NM
x4
NM
x4
NM
x4
NM
x4
87A
98C
98A
97C
97C
98A
98A
85A
87A
98B
98C
3
3
In the same way, fit the right side strip
98C to the right-hand side of the model
over the edge of the roof panels. Fix in place
to framework 87A using eight red NM
screws (inset below).
50
50
AGORAMODELS ROUTEMASTER BUS
51
AGORAMODELS ROUTEMASTER BUS
