Agora Models RM 857 - Page 9

3
4
1
2
1
Fit the window pane 92G to the inside of the left wall
framework 92A. Fix in place with four EM screws.
2
Cut away the mouldings that were used in
manufacture from the sliding window pane
92E and the window frame 92D. Smooth any
rough edges.
4
Fit the window frame
92D (with sliding
window pane 92E) on to the
outside of the left wall
framework 92A. Fit the
window pane 92F to the
inside of the framework, as
shown. Fix in place from the
inside of the window pane
92F with four OP screws.
3
Fit the sliding window pane 92E into the
window frame 92D so that ridges on the
ends of part 92E fit into the grooves in the
frame 92D. The ‘metal’ edge of the sliding
window goes at the top.
EM
x2
92G
92E
92A
92D
92D
92F
EM
x2
92A
OP
OP
92D
92E
9
9
