To fix the hull section in place you will need two

PM 2 x 4 mm silver screws.

Fix hull section 23-01 in place with the screws. Don’t

worry if there is a gap between 23-01 and the forward

section of the hull (indicated by the arrow). Identify

the raised screw sockets (circled) where connector

23-02 will fit (see next step).

Fit the connector 23-02 on the raised screw sockets

of the hull sections 23-01 and 11-01.

Fix the connector 23-02 in place with two silver PM

2 x 4 mm screws. As you tighten the screws the gap

between the hull section will disappear (see arrow).

Place the superstructure deck 23-03 on your worktop

alongside the superstructure deck 21-06 assembled

in stage 21. Fit the lip on part 21-06 over the edge of

part 23-03 as indicated by the arrows.

You will need three PB 2 x 5 mm black screws to fix

the deck sections together.
