Agora Bismarck - STAGE 27: HULL SECTION AND NAVIGATION LIGHT; 01. FITTING THE HULL SECTION

01. FITTING THE HULL SECTION
STAGE 27
HULL SECTION AND NAVIGATION LIGHT
01
Take the hull assembly from stage 25. Fit two of the
screw sockets in the connector 27-02 over two pins
on part 13-01, in the base of the hull. The arrows
indicate how it should be fitted.
Use two PM 2 x 4 mm silver screws to fix the
connector to the hull assembly.
02
COMPONENTS CHECKLIST
27-01: Fourth keel section
27-02: Connector
27-03: LED holder
27-04: Cable with LED light
27-05: Cable label
PB Two 2 x 5 mm black screws PM Five 2 x 4 mm silver screws
PM
PB
2701
2703
2704
2702
2705
1301
2702
AM
1301
2702
PM
23
23
AGORAMODELS BISMARCK
PB
AGORAMODELS BISMARCK
