Agora Bismarck - STAGE 22: THE FOURTH SECTION OF THE UPPER DECK; 01. FITTING THE BARBETTES

01. FITTING THE BARBETTES
STAGE 22
THE FOURTH SECTION
OF THE UPPER DECK
01
Place the upper deck section 22-01 on your worktop.
Take one of the two barbettes 22-02 and fit it in one
of the openings in the upper deck, as indicated.
Ensure that the square pegs at the base of barbette
22-02 fit into the recesses around the opening. You
may need to push the last pin in from the outside so
that the barette clicks into place.
02
PB
2201
2202
2202
2201
2202
NOTE:
The barbettes are
for the forward
two 15mm gun
turrets
COMPONENTS CHECKLIST
22-01: Fourth section
of the upper
deck
22-02: Two barbettes
PB: Five 2.3 x 6 mm PB
screws
