Viewed from below, you can see that all
four of the square pegs on the base of
the barbette 22-02 are fitted in place.
Repeat steps 1 to 3 to fit the second
barbette 22-02 into the right-hand
circular opening in the upper deck 22-01.
Place the upper deck section 19-01
(assembled in stage 19) on your worktop.
Take the fourth upper deck section
22-01 and fit the forward edge of 22-01
over the edge of part 19-01 so that the
four pegs on the base of 22-01 are
located in the sockets in part 19-01, as
indicated.
03
04
01
1901
2202
2201
2201
2202
2201
02. FITTING THE DECK SECTIONS TOGETHER
