Pistol-Handle Model Parts List
No. Parts Name Q'ty
1 POWER SUPPLY CORD 1
2 PRCD INTERRUPTER PROTECTION(OPTIONAL) 1
3 CORD ARMOR 1
4 CORD CLIP 1
5 SCREW M4 x 14 2
6 SWITCH LOCK-ON 1
7 TERMINAL CONNECTOR BLOCK 1/12
8 ELECTRONICS UNIT 1
9 P-HANDLE HOUSING-RIGHT 1
10 P-HANDLE HOUSING-LEFT 1
11 SCREW M4 x 20 5
12 SCREW M4 x 35 3
13 SCREW M5 x 20 4
14 SOCKET CAP SCREW M4 x 8 4
15 BRUSH SPRING 2
16 BRUSH HOLDER 2
17 INSULATION PLATE 2
18 CARBON BRUSH 7 x 17 x 19 2
19 SCREW M4 x 6 3
20 TUBULAR SPIRIT LEVEL 29 x 10 1
21 MOTOR HOUSING 1
22 STATOR 1
23 SCREW 3/16" x 3" (M5 x 75) 2
24 FAN BAFFLE 1
25 BALL BEARING 6200-LLU 1
26 ARMATURE M1.0 x 7T 1
27 BALL BEARING 6201ZZ 1
28 STAR WASHER M4 1
29 GROUND WIRE 1
30 GEAR PLATE 1
31 GASKET 1
32 BALL BEARING 608 ZZ 1
33 CLUTCH NUT M10 x P1.25 1
34 DISC SPRING Ø12.1 x Ø28 x 1.5 1
35 PRESSURE DISC 10 x Ø12 x Ø28 x 3 1
36 BRASS CLUTCH DISC Ø12.1 x Ø28 x 1 2
37 INPUT/CLUTCH GEAR M1.0 x 34T 1
38 BUSHING Ø12 x Ø18 x 4.2 1
39 PRESSURE DISC Ø12.1 x Ø30 x 0.8 1
No. Parts Name Q'ty
40 INPUT SHAFT DP20 x 21T ; M1.25 x 14T 1
41 NEEDLE BEARING HK 0810 IKO 1
42 NEEDLE BEARING HK1010 1
43 INNER CAM PLATE 1
44 COIL SPRING Ø1.0 x Ø17.2 x Ø19.2 x 3T x 15L 1
45 OUTER CAM PLATE 1
46 N/A -
47 SLIDING GEAR DP20 x 32T ; M1.25 x 41T 1
48 GEAR CASE 1
49 SOCKET CAP SCREW M5 x 12 1
50 ACTUATOR PIN 1
51 SELECTOR DISC 1
52 O-RING Ø3 x Ø20 x Ø26 1
53 GEAR SELECTOR 1
54 SPRING Ø0.8 x Ø3.4 x Ø5 x 11T x 35L 1
55 RELEASE PIN 1
56 SCREW M5 x 60 4
57 OIL SEAL Ø27 x Ø42 x 7 1
58 OIL SEAL Ø27 x Ø45 x 8 1
59 EXTERNAL CIRCLIP IS-28 1
60 BEARING 60/28 2RS 1
61 SPRING Ø1.2 x Ø28.2 x 5T x 40L 1
62 PERCUSSION SELECTOR COLLAR 1
63 ENGAGEMENT COLLAR 1
64 PARALLEL KEY 5 x 5 x 45 1
65 SPINDLE 1-1/4"-7UNC & 1/2" BSP 1
66 INTERNAL CIRCLIP R-52 1
67 N/A -
68 HANDLE CLAMP 1
69 SPACER Ø6.1 x Ø12 x 10 1
70 LOCK SCREW 1
71 FRONT HANDLE 1
72 SCREW M4 x 16 4
73 UNIVERSAL PORT 1
74 O-RING Ø22 x Ø1.5 1
75 VACUUM ADAPTOR 1
76 WATER FEED CONNECTOR KIT 1
77 WATER COUPLING 1
78 PLUG 1
