11.3 油封
Reinforced seal
附录
Appendixes
表 11-3 油封
Table 11-3 reinforced seal
安装部位
Installation location
规格
Specifications
标准号／图号
Standard code
件/台
quantity
分动箱轴承座
Transfer case bearing seat
FB30x52x7D
GB/T9877.1
2
变速箱输入轴轴承座
Bearing block for the input shaft of
FB50x72x8D
GB/T9877.1
2
动力输出轴
Power output shaft
SG60x90x12
JB2600
2
转向节立轴
Vertical shaft of steering knuckle
SD65x90x12
JB2600
8
半轴壳轴承座
Bearing block for the semi-axle housing
FB100x130x12D
GB/T9877.1
4
前桥传动轴中间支承座
Intermediate base for the front drive axle
FB30x52x7D
GB/T9877.1
2
前驱动桥前轮毂
Front wheel hub on front drive axle
165x190x7
5137109
2
前驱动桥半轴
Semi-axle of the front drive axle
40x62x12
5136002
2
前驱动桥驱动叉轴
Drive fork shaft of the front drive axle
42x62x17
5133799
2
前驱动桥小锥齿轮轴
Front drive axle bevel pinion shaft
45x75x10
5135294
1
前驱动桥壳体主销孔
Kingpin hole of the front drive axle
housing
56x70x7.5
5121471
2
动力输出轴头处油封
Oil seal at the end of power output shaft
FB70x90x10D
GB/T9877.1
2
11.4 滚动轴承
Rolling bearing
表 11-4 滚动轴承
Table 11-4 rolling bearing
安装部位
Installation position
轴承名称
Bearing name
型号
model
件／台
quantity
轴承标
准号
Bearings
standard
变速箱输入轴轴承座 单列向心球轴承
6310 1 GB/T 276
