GROSS WEIGHT - kg X 100
PRESSURE ALTITUDE - FEET X 1000
42 44 46 48 50 52 54 56 58 60 62 64
GROSS WEIGHT - POUNDS x 100
0
5
10
15
20
25
30
35
40
45
PRESSURE ALTITUDE - METERS X 100
-30
-20
-10
0
10
20
30
ISA+30
OAT LIMIT
OAT - ˚C
▼
▼
HOVERING CEILING OUT OF GROUND EFFECT
TAKE-OFF POWER
ROTOR: 102 %
ZERO WIND
ELECTRICAL LOAD: 150 A TOTAL
TR 109-60-99/II REV B
ABHD053C
CAUTION:OGE HOVER OPERATION MAY RESULT IN VIOLATION
OF H-V LIMITATIONS.
Figure 4-8. Hovering ceiling - out of ground effect - take-off power.
RFM A109E
4-14 R.A.I. Approved
Rev. 23
