GROSS WEIGHT - kg X 100
PRESSURE ALTITUDE - FEET X 1000
42 44 46 48 50 52 54 56 58 60 62 64
GROSS WEIGHT - POUNDS x 100
0
5
10
15
20
25
30
35
40
45
PRESSURE ALTITUDE - METERS X 100
-30
-20
-10
0
10
20
30
40
ISA+30
OAT LIMIT
OAT - ˚C
HOVERING CEILING OUT OF GROUND EFFECT
MAXIMUM CONTINUOUS POWER
ROTOR: 102 %
ZERO WIND
ELECTRICAL LOAD: 150 A TOTAL
TR 109-60-99/II REV B ABHD054C
CAUTION:OGE HOVER OPERATION MAY RESULT IN VIOLATION OF H-V LIMITATIONS.
Figure 4-9. Hovering ceiling - out of ground effect - maximum continuous power.
RFM A109E
R.A.I. Approved 4-15
Rev. 23
