Figure 4-10 (sheet 1 of 2). Height - velocity diagram.
20 21 22 23 24 25 26 27 28 29 30
-1
0
1
2
3
4
5
6
7
8
9
10
11
GROSS WEIGHT - kg X 100
PRESSURE ALTITUDE - FEET X 1000
46 48 50 52 54 56 58 60 62 64
GROSS WEIGHT - POUNDS x 100
0
5
10
15
20
25
30
PRESSURE ALTITUDE - METERS X 100
-30
-20
-10
0
10
20
30
40
ISA+30
OAT LIMIT
OAT - ˚C
▼
▼
HEIGHT-VELOCITY DIAGRAM
ONE ENGINE INOPERATIVE
CHART A
CHART "A" SHOWS THE WEIGHT VALUES AT/BELOW WHICH THERE IS NO H-V
LIMITATION FOR HEAVIER WEIGHTS, REFER TO CHART "B".
ABHD077D
Hd LIMIT
8000 ft
TR 109-60-99/II REV C
RFM A109E
R.A.I. Approved 4-17
Rev. 23
