AGUSTA A109E - Page 278

Figure 4-10 (sheet 2 of 2). Height - velocity diagram.
0 5 10 15 20 25 30 35 40 45 50
0
50
100
150
200
INDICATED AIRSPEED - KNOTS
WHEEL HEIGHT - FEET
HEIGHT-VELOCITY DIAGRAM
ONE ENGINE INOPERATIVE
CHART B
TR 109-60-99/II REV C ABHD078E
AVOID OPERATION
IN SHADED AREA
FOR SMOOTH, LEVEL, HARD SURFACES
WHEEL HEIGHT - METERS
10
20
30
40
50
60
0
RFM A109E
4-18 R.A.I. Approved
Rev. 23
UNMAINTAINED COPY
