NOTE
When SBY or TEST mode is selected the radar does not radiate.
As a precaution it is nevertheless convenient to operate as
follows:
- Direct nose of helicopter such that antenna scan sector is free
of large metallic objects such as hangars or other aircraft for a
distance of 30 m (100 ft) and tilt antenna fully upwards.
- Avoid radar operation during refueling of helicopter or other
refueling operations within 30 m (100 ft).
- Avoid radar operation if personnel is standing too close in the
180 degree forward sector of the helicopter.
WARNING
Avoid to set the radar ON when there is personnel within 1,5 m
(5 ft) from the radar antenna.
SECTION 3 - EMERGENCY AND MALFUNCTION
PROCEDURES
When EFIS is installed, the weather radar image is not available in Composite
mode.
SECTION 4 - PERFORMANCE DATA
No change.
RFM A109E
APPENDIX 3
Page 4 of 4 R.A.I. Approved
Rev. 11
