0 5 10 15 20 25 30 35 40 45 50
0
50
100
150
200
INDICATED AIRSPEED - KNOTS
WHEEL HEIGHT - FEET
HEIGHT-VELOCITY DIAGRAM
ONE ENGINE INOPERATIVE
AG.PDV.2005-02 Rev. A
ABHD654A
AVOID OPERATION
IN SHADED AREA
FOR SMOOTH, LEVEL, HARD SURFACES
WHEEL HEIGHT - METERS
10
20
30
40
50
60
0
H - V
(ft) (kts)
A 180 0
B 40 15
C 35 15
D 20 0
A
B
C
D
GROSS WEIGHT: UP TO 3000 kg (6613 lb)
WITHOUT EAPS AND WITH EAPS OFF/ON
ECS ON (UP TO 2000 ft-HP)
CHART B
Figure 4-4. Height-Velocity diagram - Chart B.
RFM A109E
APPENDIX 5
E.A.S.A. Approved Page 13 of 23
Rev. 44
