GROSS WEIGHT - kg X 100
PRESSURE ALTITUDE - FEET X 1000
42 44 46 48 50 52 54 56 58 60 62 64
GROSS WEIGHT - POUNDS x 100
0
5
10
15
20
25
30
35
40
45
PRESSURE ALTITUDE - METERS X 100
-10
0
10
20
30
ISA+30
OAT LIMIT
OAT - ˚C
▼
▼
HOVERING CEILING IN GROUND EFFECT
TAKE-OFF POWER
ROTOR: 102 %
E.C.S. ON
ZERO WIND
ELECTRICAL LOAD: 150 A TOTAL
TR 109-60-99/II REV C ABHD059C
WHEEL HEIGHT: 3 ft
Figure 4-5. Hovering ceiling - IGE - take-off power.
RFM A109E
APPENDIX 5
Page 14 of 23 E.A.S.A. Approved
Rev. 44
