AGUSTA A109E - Page 380

SECTION 6 - WEIGHT AND BALANCE
WEIGHTS - ARMS AND MOMENTS
LONGITUDINAL MOMENTS
USABLE FUEL - MAIN FUEL TANKS PLUS SUPPLEMENTARY TANKS
WEIGHT
(kg)
CAPACITY
(l)
(0.8 kg/l)
ARM
(mm)
MOMENT
(kgm)
20 25 3324 66.5
40 50 3327 133.1
60 75 3329 199.7
80 100 3331 266.5
100 125 3399 339.9
120 150 3461 415.3
140 175 3505 490.7
160 200 3539 566.2
180 225 3543 637.7
200 250 3551 710.2
220 275 3571 785.6
240 300 3614 867.4
260 325 3641 946.7
280 350 3668 1027.0
300 375 3691 1107.3
320 400 3711 1187.5
340 425 3729 1267.9
360 450 3746 1348.6
380 475 3760 1428.8
400 500 3773 1509.2
420 525 3785 1589.7
440 550 3796 1670.2
460 575 3806 1750.8
480 600 3815 1831.2
500 625 3823 1911.5
RFM A109E
APPENDIX 8
Page4of8
Rev. 11
