AGUSTA A109E - Page 381

(Cont.)
USABLE FUEL - MAIN FUEL TANKS PLUS SUPPLEMENTARY TANKS
WEIGHT
(kg)
CAPACITY
(l)
(0.8 kg/l)
ARM
(mm)
MOMENT
(kgm)
520 650 3831 1992.1
540 675 3838 2072.5
560 700 3845 2153.2
580 725 3851 2233.6
600 750 3857 2314.2
620 775 3863 2395.1
640 800 3868 2475.5
660 825 3873 2556.2
680 850 3883 2640.4
688 860 3887 2674.3
USABLE FUEL - MAIN FUEL TANKS PLUS RH SUPPLEMENTARY
TANK ONLY
WEIGHT
(kg)
CAPACITY
(l)
(0.8 kg/l)
ARM
(mm)
MOMENT
(kgm)
20 25 3324 66.5
40 50 3327 133.1
60 75 3329 199.7
80 100 3331 266.5
100 125 3399 339.9
120 150 3461 415.3
140 175 3505 490.7
160 200 3539 566.2
180 225 3543 637.7
200 250 3551 710.2
220 275 3571 785.6
RFM A109E
APPENDIX 8
Page5of8
Rev. 11
