AGUSTA A109E - Page 382

(Cont.)
USABLE FUEL - MAIN FUEL TANKS PLUS RH SUPPLEMENTARY
TANKS ONLY
WEIGHT
(kg)
CAPACITY
(l)
(0.8 kg/l)
ARM
(mm)
MOMENT
(kgm)
240 300 3614 867.4
260 325 3645 947.7
280 350 3671 1027.9
300 375 3695 1108.5
320 400 3715 1188.8
340 425 3733 1269.2
360 450 3750 1350.0
380 475 3764 1430.3
400 500 3778 1511,2
420 525 3796 1594.3
440 550 3816 1679.0
460 575 3834 1763.6
480 600 3851 1848.5
500 625 3866 1933.0
520 650 3880 2017.6
540 675 3893 2102.2
560 700 3906 2187.4
RFM A109E
APPENDIX 8
Page6of8
Rev. 11
UNMAINTAINED COPY
