AGUSTA A109E - Page 383

LATERAL MOMENTS
USABLE FUEL - MAIN FUEL TANKS PLUS RH SUPPLEMENTARY
TANK ONLY
WEIGHT
(kg)
CAPACITY
l
(0.8 kg/l)
ARM
(mm)
MOMENT
(kgm)
20 20 0 0.0
40 50 0 0.0
60 75 0 0.0
80 100 0 0.0
100 125 0 0.0
120 150 0 0.0
140 175 0 0.0
160 200 0 0.0
180 225 0 0.0
200 250 0 0.0
220 275 0 0.0
240 300 0 0.0
260 325 15 3.9
280 350 28 7.8
300 375 40 12.0
320 400 49 15.7
340 425 58 19.7
360 450 66 23.8
380 475 73 27.7
400 500 79 31.6
420 525 79 33.2
440 550 75 33.0
460 575 72 33.1
480 600 69 33.1
500 625 66 33.0
520 650 64 33.3
540 675 61 32.9
560 700 59 33.0
RFM A109E
APPENDIX 8
Page7of8
Rev. 11
