SECTION 6 - WEIGHT AND BALANCE
PATIENT ARM ON LITTER (-113/-179, -119/-165, -137/-173, -143 AND
-163/-183)
Longitudinal arm (STA) : 2900 mm (114.2 inches) from
STA 0.
Lateral arm (BL) : 412 mm (16.2 inches) from the
helicopter plane of simmetry.
PATIENTS ARM ON LITTER (-127/-171 AND -145)
Longitudinal arm (STA) : 2900 mm (114.2 inches) from
STA 0.
Lateral arm (BL) (left or right) : 412 mm (16.2 inches) from the
helicopter plane of simmetry.
FORWARD ATTENDANT ARM (-113/-179, -119/-165, -137/-173, -143
AND -163/-183)
Longitudinal arm (STA) : 2455 mm (96.6 inches) from
STA 0.
Lateral arm (BL) : 0 to 412 mm (16.2 inches) from
helicopter plane of simmetry.
FORWARD ATTENDANTS ARM (-131 ONLY)
Longitudinal arm (STA) : 2455 mm (96.6 inches) from
STA 0.
AFT ATTENDANT ARM (-113/-179, -119/-165, -137/-173, -143 AND
-163/-183)
Longitudinal arm (STA) : 3200 mm (126 inches) from
STA 0.
Lateral, inboard attendant arm (BL) : 0 mm.
