ELECTRONIC DISPLAY UNIT FORMATS
The EDUs present the following information:
EDU 1
-N1
- NR/N2
-TOT
- TRQ
- Caution, warning and advisory
messages
EDU 2
- Engine oil pressure
- Engine oil temperature
- Transmission oil pressure
- Transmission oil temperature
- Fuel pressure
- Fuel quantity
- Fuel flow (provision only)
- Main hydraulic pressure
- Utility hydraulic pressure
- DC ammeter
- DC voltmeter
- AC voltmeter
-OAT
- Advisory and status messages
The main display formats are:
EDU 1
-START
- CRUISE
{
AEO
OEI
AUTOROTATION
EDU 2
- MAIN
- AUXILIARY
- REVERSIONARY
{
AEO
OEI
AUTOROTATION
