For Parts and Service, contact our authorized distributor:
call 1-800-849-1297 For Technical Assistance: call 1-800-829-5886
MODEL NO. AG17542STB
17.5 HP 42 INCH
LAWN TRACTOR
191878 Rev. 1 7.28.04 TR/MH
PRINTED IN U.S.A.
• Assembly
• Operation
• Maintenance
• Service and Adjustments
• Storage
• Troubleshooting
• Repair Parts

Table of Contents

Questions and Answers

  • D
    Daniel WoodAug 23, 2025
    Why Agway AG17542STB Lawn Mower engine will not turn over?
    • M
      Melissa ThompsonAug 23, 2025
      If the engine of your Agway Lawn Mower won't turn over, here are some potential causes: * The clutch/brake pedal might not be depressed. Depress the clutch/brake pedal. * The attachment clutch might be engaged. Disengage the attachment clutch. * The battery could be weak or dead. Recharge or replace the battery. * A blown fuse could be the issue. Replace the fuse. * The battery terminals might be corroded. Clean the battery terminals. * Loose or damaged wiring could be the problem. Check all wiring. * The ignition switch might be faulty. Check or replace the ignition switch. * The solenoid or starter could be faulty. Check or replace the solenoid or starter. * Faulty operator presence switch(es). Contact a qualified service center/department.
  • P
    Phillip WhitakerAug 26, 2025
    How to fix Agway Lawn Mower that is hard to start?
    • C
      Cassie ParkerAug 26, 2025
      If your Agway Lawn Mower is hard to start, check these possible causes: * The air filter might be dirty. Clean or replace it. * The spark plug might be bad. Replace it. * The battery could be weak or dead. Recharge or replace the battery. * The fuel filter might be dirty. Replace it. * The fuel could be stale or dirty. Empty the fuel tank and refill it with fresh, clean gasoline. * Loose or damaged wiring could be the problem. Check all wiring. * The carburetor may be out of adjustment, see “To Adjust Carburetor” in the Service and Adjustments section. * Engine valves might be out of adjustment; contact a qualified service center/department.
  • W
    William ReynoldsAug 27, 2025
    What causes excessive vibration in Agway Lawn Mower?
    • N
      Nathan KennedyAug 28, 2025
      Excessive vibration in your Agway Lawn Mower can be caused by: * A worn, bent, or loose blade. Replace the blade and tighten the blade bolt. * A bent blade mandrel. Contact a qualified service center/department. * Loose or damaged parts. Tighten loose parts and replace damaged parts.
  • C
    Catherine Davis DDSAug 30, 2025
    What to do if Agway Lawn Mower engine clicks but will not start?
    • V
      Vincent TurnerAug 30, 2025
      If your Agway Lawn Mower engine clicks but won't start, the following could be the reasons: * The battery might be weak or dead. Recharge or replace the battery. * The battery terminals might be corroded. Clean the battery terminals. * Loose or damaged wiring could be the problem. Check all wiring. * The solenoid or starter could be faulty. Check or replace the solenoid or starter.
  • S
    Stephanie WilliamsSep 4, 2025
    How to fix poor and uneven cut of Agway AG17542STB?
    • D
      Deborah PerrySep 4, 2025
      If your Agway Lawn Mower is giving a poor, uneven cut, check the following: * The blade might be worn, bent, or loose. Replace the blade and tighten the blade bolt. * The mower deck might not be level. Level the mower deck. * There could be a buildup of grass, leaves, and trash under the mower. Clean the underside of the mower housing. * A bent blade mandrel. Contact a qualified service center/department. * Clogged mower deck vent holes from buildup of grass, leaves, and trash around mandrels. Clean around mandrels to open vent holes.
  • V
    veronica56Sep 6, 2025
    What to do if Agway AG17542STB blades will not rotate?
    • A
      amanda09Sep 6, 2025
      If the blades of your Agway Lawn Mower won't rotate, consider the following: * There might be an obstruction in the clutch mechanism. Remove the obstruction. * The mower drive belt might be worn or damaged. Replace the mower drive belt. * The idler pulley might be frozen. Replace the idler pulley. * The blade mandrel might be frozen. Contact a qualified service center/department.
  • C
    catherine35Sep 8, 2025
    Why Agway AG17542STB Lawn Mower engine continues to run when operator leaves seat with attachment clutch engaged?
    • M
      Matthew CarterSep 8, 2025
      If your Agway Lawn Mower engine continues to run when the operator leaves the seat with the attachment clutch engaged, it could be due to: * A faulty operator-safety presence control system. Check the wiring, switches, and connections. If problems persist, contact a qualified service center/department.
  • K
    Karen CruzSep 12, 2025
    How to fix Agway AG17542STB headlight(s) not working?
    • E
      ewadeSep 12, 2025
      If the headlight(s) on your Agway Lawn Mower are not working, check these items: * The switch might be “OFF”. Turn the switch “ON.” * The bulb(s) or lamp(s) might be burned out. Replace the bulb(s) or lamp(s). * The light switch might be faulty. Check or replace the light switch. * Loose or damaged wiring could be the issue. Check the wiring and connections. * A blown fuse could be the problem. Replace the fuse.
  • D
    Dr. Dale NicholsSep 13, 2025
    Why Agway AG17542STB Lawn Mower battery will not charge?
    • C
      Charles WebbSep 13, 2025
      If your Agway Lawn Mower battery will not charge, consider these possible causes: * The battery might have bad cell(s). Replace the battery. * There might be poor cable connections. Check and clean all connections. * The regulator might be faulty (if so equipped). Replace the regulator. * The alternator might be faulty. Replace the alternator.
  • M
    Michelle DaySep 15, 2025
    Why does Agway Lawn Mower engine “backfires” when turning engine “OFF”?
    • L
      Laura BriggsSep 16, 2025
      The Agway Lawn Mower engine might “backfire” when turning the engine “OFF” because: * The engine throttle control was not set at the “SLOW” position for 30 seconds before stopping the engine. Move the throttle control to the “SLOW” position and allow it to idle for 30 seconds before stopping the engine.

Summary

Warranty Information

Limited Warranty

Manufacturer's warranty terms, limitations, and exclusions for the product.

Safety Rules

General Operation

Essential safety guidelines for operating the tractor and mower safely.

Slope Operation

Precautions and instructions for safely operating the tractor on slopes.

Children

Guidelines to ensure the safety of children around the tractor.

Service

Safety measures to follow when performing maintenance or repairs.

Product Specifications

Product Specifications

Technical details and specifications of the lawn tractor, including fluid capacities.

Customer Responsibilities

Outlines the owner's duties for safe operation and maintenance of the tractor.

Assembly;Pre-Operation

Tools Required for Assembly

Lists the necessary tools for assembling the tractor.

Remove Tractor from Carton

Guide on how to safely unpack the tractor from its shipping carton.

Attach Steering Wheel

Detailed steps for installing the steering wheel assembly.

Install Seat

Instructions for properly fitting and securing the tractor seat.

Checklist

A checklist to ensure all necessary pre-operation steps are completed for safe use.

Operation

Know Your Tractor

Identifies and explains the location and function of all tractor controls and instruments.

Set Parking Brake

Procedure for engaging and ensuring the tractor's parking brake is secure.

Stopping

Instructions on how to safely stop the mower blades, ground drive, and engine.

Adjust Mower Cutting Height

Guide on how to set the desired grass cutting height using the lift lever.

Operate on Hills

Crucial safety advice and techniques for operating the tractor on sloped terrain.

Start Engine

Step-by-step guide for starting the tractor engine, including warm and cold weather.

Mowing Tips

Advice for optimal mowing performance, grass cutting, and mower deck setup.

Maintenance

Maintenance Schedule

A detailed schedule of required maintenance tasks based on operating hours and time.

General Recommendations

General advice and important notes for maintaining the tractor.

Before Each Use

Essential daily checks to perform before operating the tractor.

Lubrication Chart

Specifies points requiring lubrication and the types of lubricants to use.

Battery

Instructions for battery charging, cleaning, and maintenance.

Change Engine Oil

Detailed steps for draining old engine oil and refilling with new oil.

Clean Air Screen

Procedures for cleaning the air screen and air filter for engine cooling.

Service and Adjustments

Remove Mower

Step-by-step instructions for detaching the mower deck from the tractor.

Install Mower

Step-by-step instructions for attaching the mower deck to the tractor.

Level Mower Housing

Guide on how to adjust the mower deck for optimal and even cutting performance.

Check and Adjust Brake

Procedures for checking brake performance and making necessary adjustments.

Replace Motion Drive Belt

Instructions for removing and installing the motion drive belt.

Start Engine with Weak Battery

Guide on how to safely jump-start the tractor using jumper cables.

Replace Battery

Instructions for safely removing and installing a new tractor battery.

Storage

Tractor Storage Preparation

Steps for cleaning, inspecting, and preparing the tractor itself for storage.

Engine Fuel System Storage

Procedures for preparing the fuel system for storage to prevent gumming and fuel degradation.

Battery Storage Recommendations

Guidelines for proper battery charging and storage to maintain its health.

Troubleshooting Chart

Will not start

Identifies causes and solutions for the tractor failing to start.

Hard to start

Diagnoses and remedies for difficulties in starting the tractor engine.

Engine will not turn over

Troubleshooting steps when the engine fails to crank or turn.

Loss of power

Addresses causes and fixes for reduced engine power or performance.

Poor cut - uneven

Solutions for issues causing an uneven or poor quality grass cut.

Mower blades will not rotate

Diagnoses and fixes for the mower blades failing to engage or spin.

Poor grass discharge

Addresses problems related to inadequate discharge of grass clippings.

Battery will not charge

Solutions for issues preventing the tractor battery from charging.

Suggested Guide for Sighting Slopes for Safe Operation

Sighting Slopes for Safe Operation

A method to visually measure and assess slope angles for safe operation.
