Mechanical
Swing Type EM3 Plus EM 3 EM 2
Max. Piston Stroke 450 mm 350 mm 200 mm
Max. Length of motor 1255 mm 1030 mm 730 mm
Max. Leaf's Weight 300 kg/ Leaf 300 kg/ Leaf 300 kg/ Leaf
Suitable Leaf's Length 2 to 3.5 meter/ Leaf 1.5 to 2.5 meter/ Leaf 1 to 1.6 meter/ Leaf
Frame Housing
Driving Method
Opening Degree
90 Degree Rotation Time
Temperature
0 to 110 degree
8 to 12 seconds
-25℃ to +55℃
Screw Driven Piston Type
DC 24V
Over Current Detection
Microcontroller Based
Infrared Beam Sensor (Optional)
Stainless Steel / Aluminum Alloy
IP66
