Controlling via VISCA over IP (Ethernet)
STEP 3: To connect an IP camera, press the button SETUP found on the bottom left of the CCU-MINI. The default IP address of the CCU-MINI is:
192.168.1.108
To change the IP address, head to page 05/08 labeled IP MODE: STATIC
You can change the status to DHCP by tilting the joystick left or right, and selecting ENTER to conrm your selection.
Alternatively, you can press ENTER on IP MODE: STATIC to set your own IP address if necessay.
STEP 3a: Under the menu, head to page 01/08: Add Net Dev. From there, follow the prompt to address the camera position number, MODE, IP, MASK,
and GATEWAY of the camera you are trying to control.
STEP 3b: Once complete, you will be able to connect up to seven compatible cameras. Hit the ESC key to exit the menu.
STEP 3c: To select a registered controller, select the CAM button near the bottom left of the controller. Next, input the camera number you want to con-
trol and then click ENTER to select the camera. From here, you will have full control of the camera.
