Controlling via Serial VISCA (RS232, RS422, RS485)
STEP 4: To connect a Serial camera, press the SETUP and head to
menu page 03/08 - labeled Switch to Ana
Press ENTER to accept and give the device a few minutes to update
STEP 4a: To add a Serial camera, head into the menu again to page
02/08: Add Ana Dev. Click ENTER - the device will ask for the
Camera ID (Important: NEEDS TO MATCH CAMERA’S ADDRESS
NUMBER), Mode (PelcoD/PelcoP = RS485, VISCA = RS232/RS422)
and baudrate.
STEP 4b: Once complete, you will be able to connect up to seven
compatible cameras. Hit the ESC key to exit the menu.
STEP 4c: To select a registered controller, select the CAM button
near the bottom left of the controller. Next, input the camera num-
ber you want to control and then click ENTER to select the camera.
From here, you will have full control of the camera.
STEP 5: With the CCU-MINI, you can adjust point/tilt/zoom speed,
change & adjust the focus mode and set presets. To set a preset
for any camera, press any DIGIT (0-9) key and hold it until the
PRESET sign on the controller disappears.
To access the preset, press the corresponding DIGIT for the as-
signed preset.
END QUICK START GUIDE
