SmartyCam HD connections
SmartyCam HD features two connectors in
the back.
The four-pin connector is used only for con-
necting an external GPS receiver (module
AiM GPS05B).
CHAPTER 1
10
CAN - Power ConnectionGPS05B Connection
The five-pin connector is used for connec-
ting an external power and the CAN net.
