1.2 Overview
6
11
12
3
4
7
5
2
1
8
9A
9B
10
1 Push-buttons
2 Front ip-up lens cover
3 Torx T10 tool
4 Battery cap
5 Battery (CR2032)
6 Windage adjuster
7 Elevation adjuster
8 Rear ip-up lens cover
9 A Mount base 30 mm
B Mount base 39 mm
10 Screws for mount (4 pcs)
11 Locking bar
12 Screw for locking bar
Fig. 1 Overview
