Customer : CSN
Type : A318/A319/A320/A321
Rev. Date : May 01, 2018
Manual : AMM
Selected applicability : 0054-0054
29-32-12 PB 401 CONF 00 - PRESSURE
SWITCH - SYSTEM - REMOVAL/INSTALLATION
Print Date: July 05, 2018 Page 11 of 19
© AIRBUS S.A.S. ALL RIGHTS RESERVED. CONFIDENTIAL AND PROPRIETARY DOCUMENT.
WARNING: MAKE SURE THAT THE TRAVEL RANGES OF THE FLIGHT CONTROL SURFACES ARE
CLEAR BEFORE YOU PRESSURIZE/DEPRESSURIZE A HYDRAULIC SYSTEM.
WARNING: MAKE SURE THAT THE GROUND SAFETY-LOCKS ARE IN POSITION ON THE LANDING
GEAR. THIS WILL PREVENT UNWANTED MOVEMENT OF THE LANDING GEAR, AND THUS
POSSIBLE INJURY TO PERSONS AND DAMAGE TO THE AIRCRAFT AND/OR EQUIPMENT.
FIN : 2151GN
1. Reason for the Job
Self explanatory
2 Job Set-up Information
A. Fixtures, Tools, Test and Support Equipment
REFERENCE QTY DESIGNATION
No specific 1 CONTAINER - HYDRAULIC FLUID RESISTANT
No specific 2 WARNING NOTICE(S)
No specific Torque wrench: range to between 3.186 and 3.470 m.daN
(23.50 and 25.59 lbf.ft)
B. Consumable Materials
REFERENCE DESIGNATION
(Material No. 02ABA1) Phosphate Ester Hydraulic Fluid-General Power - -
C. Work Zones and Access Panels
ZONE/ACCESS ZONE DESCRIPTION
195BB
D. Expendable Parts
FIG.ITEM DESIGNATION IPC-CSN
3 O-ring 29-32-03-02-070
3 O-ring 29-32-83-02-100
E. Referenced Information
REFERENCE DESIGNATION
(Ref. 20-28-00-912-004-A). Electrical Bonding of Components With Conductive Bolts and Screws
and Bonding Straps in the Fuselage and in the Wings (this does not in-
clude the tanks)
(Ref. 29-00-00-864-001-A). Put the Related Hydraulic System in the Depressurized Configuration
before Maintenance Action
(Ref. 29-00-00-910-002-A). Safety Procedures of the Hydraulic System
(Ref. 29-10-00-863-003-A). Pressurize the Blue Hydraulic System with a Hydraulic Ground Power-
Cart
(Ref. 29-10-00-863-003-A-01). Pressurize the Blue Hydraulic System with the Blue Electric Pump
To Next Page
