AIREDALE SmartCool D - Cooling Duties - Free Cooling (W2 F0)

SmartCool
TM
- D
Precision Air Conditioning
106
Precision Air Conditioning
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Cooling Duties
Chilled Water Inlet and Outlet Temperatures
Model Air On
5 / 10 °C 7 / 12 °C 8 / 14 °C 10 / 16 °C 5.5 / 14.5°C
Temp. (°C) / %RH
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
SC19D033-W2C0-0
1 x DR40
22 / 50 68.2 54.8 49.3 44.9 40.2 40.2 31.4 31.4 21.3 21.3
24 / 45 77.8 63.1 61.6 55.9 49.1 49.1 40.9 40.9 48.1 48.1
26 / 40 86.2 71.4 70.0 64.3 57.7 57.7 49.7 49.7 58.1 58.1
SC19D038-W2C0-0
1 x DR55
22 / 50 75.5 61.7 55.1 51.3 45.4 45.4 35.6 35.6 22.2 22.2
24 / 45 86.2 71.1 67.9 63.1 55.3 55.3 46.1 46.1 54.8 54.8
26 / 40 95.5 80.6 74.7 68.8 65.0 65.0 56.0 56.0 65.8 65.8
SC19D045-W2C0-0
1 x DR55
22 / 50 85.0 71.1 62.3 62.3 52.2 52.2 41.2 41.2 50.0 50.0
24 / 45 97.3 81.9 74.4 69.8 63.6 63.6 53.0 53.0 63.5 63.5
26 / 40 108.1 92.9 85.2 80.8 74.7 74.7 64.3 64.3 75.8 75.8
SC19D064-W2C0-0
1 x DR95
22 / 50 85.0 71.1 62.3 62.3 52.2 52.2 41.2 41.2 50.0 50.0
24 / 45 97.3 81.9 74.4 69.8 63.6 63.6 53.0 53.0 63.5 63.5
26 / 40 108.1 92.9 85.2 80.8 74.7 74.7 64.3 64.3 75.8 75.8
SC19D070-W2C0-0
1 x DR95
22 / 50 85.0 71.1 62.3 62.3 52.2 52.2 41.2 41.2 50.0 50.0
24 / 45 97.3 81.9 74.4 69.8 63.6 63.6 53.0 53.0 63.5 63.5
26 / 40 108.1 92.9 85.2 80.8 74.7 74.7 64.3 64.3 75.8 75.8
SC19D076-W2C0-0
1 x DR95 (EC)
22 / 50 85.0 71.1 62.3 62.3 52.2 52.2 41.2 41.2 50.0 50.0
24 / 45 97.3 81.9 74.4 69.8 63.6 63.6 53.0 53.0 63.5 63.5
26 / 40 108.1 92.9 85.2 80.8 74.7 74.7 64.3 64.3 75.8 75.8
SC25D045-W2C0-0
1 x DR65
22 / 50 100.7 79.5 78.0 69.4 60.3 60.3 48.6 48.6 62.0 62.0
24 / 45 114.1 91.2 91.4 81.1 72.4 72.4 61.0 61.0 79.5 76.0
26 / 40 126.0 103.0 103.1 92.9 84.3 84.3 73.1 73.1 91.3 84.7
SC25D050-W2C0-0
1 x DR70
22 / 50 109.2 86.9 84.2 75.8 65.8 65.8 53.0 53.0 67.8 67.8
24 / 45 123.8 99.7 98.8 88.7 79.0 79.0 66.5 66.5 84.5 80.3
26 / 40 136.7 112.6 111.6 101.6 92.0 92.0 79.8 79.8 98.9 93.5
SC25D055-W2C0-0
1 x DR70
22 / 50 117.2 94.0 90.1 82.1 71.1 71.1 57.3 57.3 73.4 73.4
24 / 45 132.9 107.9 105.8 96.0 85.4 85.4 71.9 71.9 90.6 87.8
26 / 40 147.0 122.0 119.7 110.1 99.6 99.6 86.3 86.3 106.1 102.2
SC25D067-W2C0-0
1 x DR95
22 / 50 117.2 94.0 90.1 82.1 71.1 71.1 57.3 57.3 73.4 73.4
24 / 45 132.9 107.9 105.8 96.0 85.4 85.4 71.9 71.9 90.6 87.8
26 / 40 147.0 122.0 119.7 110.1 99.6 99.6 86.3 86.3 106.1 102.2
SC25D073-W2C0-0
1 x DR95
22 / 50 117.2 94.0 90.1 82.1 71.1 71.1 57.3 57.3 73.4 73.4
24 / 45 132.9 107.9 105.8 96.0 85.4 85.4 71.9 71.9 90.6 87.8
26 / 40 147.0 122.0 119.7 110.1 99.6 99.6 86.3 86.3 106.1 102.2
SC25D080-W2C0-0
1 x DR95 (EC)
22 / 50 117.2 94.0 90.1 82.1 71.1 71.1 57.3 57.3 73.4 73.4
24 / 45 132.9 107.9 105.8 96.0 85.4 85.4 71.9 71.9 90.6 87.8
26 / 40 147.0 122.0 119.7 110.1 99.6 99.6 86.3 86.3 106.1 102.2
SC31D055-W2C0-0
1 x DR70
22 / 50 117.0 90.1 92.1 78.7 71.1 67.7 56.6 56.6 82.6 73.8
24 / 45 132.0 103.0 107.0 91.6 91.0 91.0 70.1 70.1 99.8 88.0
26 / 40 145.2 116.1 120.1 104.7 98.7 91.8 83.4 83.4 114.5 101.9
SC31D065-W2C0-0
1 x DR95
22 / 50 133.3 103.7 104.5 90.6 79.8 79.8 64.9 64.9 93.1 84.8
24 / 45 150.5 118.7 121.6 105.6 97.4 92.6 80.5 80.5 112.6 101.0
26 / 40 165.8 133.8 136.7 120.8 112.7 107.8 95.9 95.9 129.3 117.1
SC31D075-W2C0-0
1 x DR95
22 / 50 148.7 116.8 116.1 102.1 89.6 89.6 72.8 72.8 102.8 95.2
24 / 45 168.0 133.7 135.2 119.1 107.0 107.0 90.5 90.5 124.4 113.6
26 / 40 185.1 151.0 152.1 136.3 124.2 124.2 107.9 107.9 143.1 131.7
SC31D077-W2C0-0
1 x DR95
22 / 50 148.7 116.8 116.1 102.1 89.6 89.6 72.8 72.8 102.8 95.2
24 / 45 168.0 133.7 135.2 119.1 107.0 107.0 90.5 90.5 124.4 113.6
26 / 40 185.1 151.0 152.1 136.3 124.2 124.2 107.9 107.9 143.1 131.7
SC31D080-W2C0-0
1 x DR95 (EC)
22 / 50 148.7 116.8 116.1 102.1 89.6 89.6 72.8 72.8 102.8 95.2
24 / 45 168.0 133.7 135.2 119.1 107.0 107.0 90.5 90.5 124.4 113.6
26 / 40 185.1 151.0 152.1 136.3 124.2 124.2 107.9 107.9 143.1 131.7
SC31D083-W2C0-0
1 x DR95 (EC)
22 / 50 148.7 116.8 116.1 102.1 89.6 89.6 72.8 72.8 102.8 95.2
24 / 45 168.0 133.7 135.2 119.1 107.0 107.0 90.5 90.5 124.4 113.6
26 / 40 185.1 151.0 152.1 136.3 124.2 124.2 107.9 107.9 143.1 131.7
TC = Total Cooling, SC =Sensible Cooling, THR = Total Heat Rejection
(1) All data quoted is gross
(2) Deduct fan gain for net duties, refer to Mechanical Data,
(3) Water Flow rate (l/s)= TC/(4.19 x ∆T) at 100% Water
W2C0
