Mechanical Data - C000 Continued
SC25D090-C000-0 SC25D100-C000-0 SC25D110-C000-0
Capacity
(1)
Nom Cooling (Gross) kW 102.1 111.4 120.5
Fan Gain (3) kW 2.24 2.65 3.01
Dimensions - W x D x H
mm 2549 x 890 x 1980 2549 x 890 x 1980 2549 x 890 x 1980
Weight - Machine / operating
kg 840 / 920 840 / 920 840 / 920
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black Grey (RAL 7021)
Material/Colour Frame: Anodised Aluminium Frame with Black Nylon Corners
Cooling Coil
Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum stages 1 (Modulated) / 1
Water volume l 71.5 71.5 85.9
Water flow rate l/s 4.34 4.61 4.86
Pressure drop kPa 18.02 18.79 19.54
Fan & Motor
Centrifugal direct drive
Motor Type AC AC AC
Quantity x Motor Size kW 3 x 2.38 3 x 2.38 3 x 2.38
Speed @25Pa ESP Maximum ESP rpm 1092 / 1364 1220 / 1364 1364 / 1364
Maximum ESP Pa 328 188 20
Nominal Airflow m³/s 5.3 5.9 6.5
Connections
Water Inlet / Outlet - mm 54 54 54
Condensate Drain Hose mm 22 22 22
Filtration Disposable to BS EN 779-G4
Quantity 4 4 4
OPTIONAL EXTRAS
Electric Heating (Total) kW 31.5
31.5
Humidifier
Capacity kg/hr
15 15
15
Feed/Drain
3/4" BSPF Braided flexible hose / 19mm hose connection
Condensate Pump
Head m
10 10
10.8
Flow l/m
5 5
5
Drain
10mm Stainless Steel Stub Connection
First upgrade Fan Motor - EC Motor Centrifugal direct drive
Quantity x Motor Size kW 3 x 2.2 3 x 2.2 3 x 2.2
Speed @ 25Pa / Maximum ESP rpm 1074 / 1360 1200 / 1360 1337 / 1360
Maximum ESP Pa 314 188 45
Fan Gain (3) kW 1.4 1.92 2.6
Second upgrade Fan Motor - EC Motor
Centrifugal direct drive
Quantity x Motor Size kW 3 x 3.1 3 x 3.1 3 x 3.1
Speed @ 25Pa / Maximum ESP rpm 1095 / 1520 1225 / 1520 1354 / 1520
Maximum ESP Pa 464 337 195
Fan Gain (3) kW 1.4
1.92 2.6
Low Pressure Hot Water
(2)
Copper Tube/Aluminium Fin
Capacity Gross kW 32.7
34.2 36.6
Water Flow (Nominal) l/s
0.76
0.73
Pressure drop kPa
21.0
20.2
LPHW Connection Sizes mm
22
22
(1) Entering air 24°C/ 45% RH water 7°C/ 12°C
(2) Based upon low pressure hot water 82°C inlet/71°C outlet. Air on 20°C
(3) Fan gain based on 25Pa ESP @ nominal air volume. Fan gain figure will change as airflow and ESP change.
