AIREDALE SmartCool D - C000 Mechanical Data Continued

SmartCool
TM
- D
Precision Air Conditioning
146
Precision Air Conditioning
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Mechanical Data - C000 Continued
SC31D110-C000-0 SC31D130-C000-0 SC31D150-C000-0
Capacity
(1)
Nom Cooling (Gross) kW 117.4 135.2 152.2
Fan Gain (3) kW 1.25 2.06 3.22
Dimensions - W x D x H
mm 3113 x 890 x 1980 3113 x 890 x 1980 3113 x 890 x 1980
Weight - Machine
kg 1000 / 1080 1000 / 1080 1000 / 1080
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black Grey (RAL 7021)
Material/Colour Frame: Anodised Aluminium Frame with Black Nylon Corners
Cooling Coil
Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages 1 (Modulated) / 1
Water volume l 85.9 85.9 85.9
Water flow l/s 4.81 5.33 5.77
Pressure drop kPa 21.2 22.88 24.46
Fan & Motor
Centrifugal direct drive
Motor Type EC EC EC
Quantity x Motor Size kW 3 x 3.1 3 x 3.1 3 x 3.1
Speed @25Pa / Maximum ESP RPM 1061 / 1520 1261 / 1520 1479 / 1520
Maximum ESP Pa 528 330 77
Nominal Airflow m³/s 5.8 6.9 7.9
Connections
Water Inlet / Outlet mm 54 54 54
Condensate Drain Hose mm 22 22 22
Filtration Disposable to BS EN 779-G4
Quantity 4 4 4
OPTIONAL EXTRAS
Electric Heating (Total) kW 31.5 31.5 31.5
Humidifier
Capacity kg/hr 15 15 15
Feed/Drain
3/4" BSPF Braided flexible hose / 19mm hose connection
Condensate Pump
Head m 10 10 10
Flow l/m 5 5 5
Drain 10mm Stainless Steel Stub Connection
First upgrade
Fan Motor
-
EC Motor
Quantity x Motor Size kW N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm N/A N/A N/A
Maximum ESP Pa N/A N/A N/A
Fan Gain (3) kW N/A N/A N/A
Second upgrade
Fan Motor
-
EC Motor
Quantity x Motor Size kW N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm N/A N/A N/A
Maximum ESP Pa N/A N/A N/A
Fan Gain (3) kW N/A N/A N/A
Low Pressure Hot Water
(2)
Capacity Gross kW 39.8 42.7 45.2
Water Flow (Nominal) l/s 0.88 0.95 1.01
Pressure drop kPa 35.9 37.4 38.8
LPHW Connection Sizes mm 22 22 22
(1) Entering air 24°C/ 45% RH water 7°C/ 12°C
(2) Based upon low pressure hot water 82°C inlet/71°C outlet. Air on 20°C
(3) Fan gain based on 25Pa ESP @ nominal air volume. Fan gain figure will change as airflow and ESP change.
C000
