Electrical Data - C000
SC19D065-C000-0 SC19D075-C000-0 SC19D090-C000-0
Unit Data Full Function C000
(1)
Nominal Run Amps A 69.3 69.3 69.3
Maximum Start Amps A 69.3 69.3 69.3
Recommended Mains Fuse Size A 80 80 80
Max Mains Incoming Cable Size mm² 35 35 35
Mains Supply V 400V / 3PH + N / 50Hz
Control circuit VAC 24 24 24
Unit Data Cooling Only C000
Nominal Run Amps A 7.6 7.6 7.6
Maximum Start Amps A 7.6 7.6 7.6
Recommended Main Fuse Size A 10 10 10
Evaporator Fan - Motor - Per Fan
Motor Type EC EC EC
Quantity x Motor Size (2) kW 2 x 2.2 2 x 2.2 2 x 2.2
Full Load Amps A 3.3 3.3 3.3
Locked Rotor Amps A 3.3 3.3 3.3
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat 3 3 3
Number of Elements 9 9 9
Rating (Total) kW 31.5 31.5 31.5
Current Per Phase A 45.5 45.5 45.5
Humidifier
Capacity kg/hr 15 15 15
Rating kW 11.25 11.25 11.25
Full Load Amps A 16.2 16.2 16.2
First upgrade EC Motor - Per Fan
Quantity x Motor Size kW 2 x 3.1 2 x 3.1 2 x 3.1
Full Load Amps A 4.8 4.8 4.8
Locked Rotor Amps A 4.8 4.8 4.8
Second upgrade EC Motor - Per Fan
Quantity x Motor Size kW N/A N/A N/A
Full Load Amps A N/A N/A N/A
Locked Rotor Amps A N/A N/A N/A
(1) Values given for function units with standard selections for heating, humidification, supply air fans.
(2) Stated motor power is based on maximum electrical power absorbed
SC25D090-C000-0 SC25D100-C000-0 SC25D110-C000-0
Unit Data Full Function C000
(1)
Nominal Run Amps A 77.7 77.7 77.7
Maximum Start Amps A 115.2 115.2 115.2
Recommended Mains Fuse Size A 100 100 100
Max Mains Incoming Cable Size mm² 35 35 35
Mains Supply V 400V / 3PH + N / 50Hz
Control circuit VAC 24 24 24
Unit Data Cooling Only C000
Nominal Run Amps A 16 16 16
Maximum Start Amps A 53.5 53.5 53.5
Recommended Main Fuse Size A 32 32 32
Evaporator Fan - Motor - Per Fan
Motor Type AC AC AC
Quantity x Motor Size (2) kW 3 x 2.38 3 x 2.38 3 x 2.38
Full Load Amps A 5 5 5
Locked Rotor Amps A 17.5 17.5 17.5
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat 3 3 3
Number of Elements 9 9 9
Rating (Total) kW 31.5 31.5 31.5
Current Per Phase A 45.47 45.47 45.47
Humidifier
Capacity Kg 15 15 15
Rating kW 11.25 11.25 11.25
Full Load Amps A 16.2 16.2 16.2
First upgrade Fan Motor - EC Motor - Per Fan
Quantity x Motor Size kW 3 x 2.2 3 x 2.2 3 x 2.2
Full Load Amps A 3.3 3.3 3.3
Locked Rotor Amps A 3.3 3.3 3.3
Second upgrade Motor - EC Motor - Per Fan
Quantity x Motor Size kW 3 x 3.1 3 x 3.1 3 x 3.1
Full Load Amps A 4.8 4.8 4.8
Locked Rotor Amps A 4.8 4.8 4.8
(1) Values given for function units with standard selections for heating, humidification, supply air fans.
(2) Stated motor power is based on maximum electrical power absorbed
