AIREDALE SmartCool D - Chilled Water Dual Circuit (C0 C0) Performance Data; C0 C0 Cooling Duties Performance Data

SmartCool
TM
- D
Precision Air Conditioning
152
Precision Air Conditioning
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Chilled Water Dual Circuit (C0C0)
Performance Data – Chilled Water – Dual Circuit
Cooling Duties
C0C0
Chilled Water Inlet / Outlet Temperatures
Model
Air On
db °C 5 / 10°C 7 / 12 °C 8 / 14 °C 10 /16 °C 5.5 / 14.5°C
%RH
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
SC19D033-C0C0-0
22 / 50 53.9 47.6 39.5 39.5 33.6 33.6 26.5 26.5 32.3 32.3
24 / 45 60.9 54.3 46.5 46.5 40.5 40.5 33.8 33.8 40.5 40.5
26 / 40 67.0 61.0 52.4 52.4 47.1 47.1 40.5 40.5 47.8 47.8
SC19D038-C0C0-0
22 / 50 59.1 53.3 44.1 44.1 37.6 37.6 29.7 29.7 36.6 36.6
24 / 45 67.1 60.8 51.4 51.4 45.2 45.2 37.7 37.7 45.4 45.4
26 / 40 73.8 68.3 58.6 58.6 52.6 52.6 45.3 45.3 53.4 53.4
SC19D045-C0C0-0
22 / 50 65.9 60.9 50.3 50.3 42.7 42.7 33.8 33.8 42.0 42.0
24 / 45 74.9 69.5 58.6 58.6 51.5 51.5 42.9 42.9 51.8 51.8
26 / 40 82.4 78.2 66.9 66.9 59.9 59.9 51.6 51.6 60.9 60.9
SC25D045-C0C0-0
22 / 50 80.3 68.7 59.7 57.2 49.8 49.8 40.1 40.1 51.5 51.5
24 / 45 90.3 78.1 71.2 69.5 59.3 59.3 49.9 49.9 61.7 61.7
26 / 40 98.8 87.5 78.1 75.4 68.4 68.4 59.2 59.2 73.7 73.7
SC25D050-C0C0-0
22 / 50 86.3 74.7 64.3 63.0 54.1 54.1 43.5 43.5 55.8 55.8
24 / 45 97.1 84.9 74.8 72.5 64.3 64.3 54.1 54.1 66.8 66.8
26 / 40 106.3 95.2 84.2 83.2 74.3 74.3 64.2 64.2 77.3 77.3
SC25D055-C0C0-0
22 / 50 92.0 80.5 67.1 67.1 58.1 58.1 46.7 46.7 60.0 60.0
24 / 45 103.6 91.6 79.8 79.1 69.2 69.2 58.1 58.1 71.9 71.9
26 / 40 113.4 102.7 89.9 89.9 80.0 80.0 69.1 69.1 83.1 83.1
SC31D055-C0C0-0
22 / 50 89.4 76.6 66.2 63.8 55.2 55.2 44.2 44.2 55.9 55.9
24 / 45 100.6 87.1 79.1 77.5 65.8 65.8 55.3 55.3 67.7 67.7
26 / 40 110.3 97.5 86.9 83.9 76.1 76.1 65.8 65.8 78.7 78.7
SC31D065-C0C0-0
22 / 50 100.3 87.5 72.9 72.9 62.9 62.9 50.3 50.3 63.9 63.9
24 / 45 113.1 99.6 87.0 85.6 75.0 75.0 62.9 62.9 77.2 77.2
26 / 40 124.1 111.7 98.2 98.2 86.9 86.9 75.0 75.0 89.8 89.8
SC31D075-C0C0-0
22 / 50 110.4 97.9 81.5 81.5 70.1 70.1 56.1 56.1 71.4 71.4
24 / 45 124.6 111.5 94.6 94.6 83.8 83.8 70.2 70.2 86.2 86.2
26 / 40 136.7 125.1 107.5 107.5 97.1 97.1 83.8 83.8 100.2 100.2
TC = Total Cooling, SC =sensible cooling,
(1) All data quoted is gross
(2) Deduct fan gain for net duties, refer to Mechanical Data
(3) Water Flow rate (l/s)= TC/(4.19 x ∆T) at 100% Water
(4) Refer to Waterside pressure Drop (kPa) on page
