AIREDALE SmartCool D - Dry Cooler Performance Data

SmartCool
TM
- D
Precision Air Conditioning
204
Precision Air Conditioning
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Performance Data – Dry Coolers
Standard Dry Cooler
Fan
Water Entering / Leaving
Ambient
Temperature °C 25°C 30°C 35°C 40°C 45°C
Output
(kW)
Output
(kW)
Output
(kW)
Output
(kW)
Output
(kW)
DR10
35°C/30°C 11 - - - -
40°C/35°C 19.6 11 - - -
45°C/40°C 28.1 19.6 11.1 - -
50°C/45°C 36.6 28 19.6 11.1 -
55°C/50°C 45 36.4 27.9 19.5 11.1
DR12
35°C/30°C 13.6 - - - -
40°C/35°C 24.5 13.7 - - -
45°C/40°C 35.2 24.5 13.7 - -
50°C/45°C 45.9 35.1 24.5 13.8 -
55°C/50°C 56.6 45.7 35.05 4.4 13.8
DR15
35°C/30°C 15..4 - - - -
40°C/35°C 25.6 15.3 - - -
45°C/40°C 35.6 25.4 15.3 - -
50°C/45°C 45.4 35.2 25.2 15.2 -
55°C/50°C 55.2 44.9 34.9 25 15.1
DR20
35°C/30°C 18.3 - -
- -
40°C/35°C 31.9 18.3
- - -
45°C/40°C 45.1 31.7 18.3
- -
50°C/45°C 58.1 44.8 31.6 18.3
-
55°C/50°C 71.5 57.7 44.4 31.4 18.3
DR25
35°C/30°C 24.4 - - - -
40°C/35°C 43.1 24.5 - - -
45°C/40°C 61.5 43 24.5 - -
50°C/45°C 79.7 61.2 42.9 24.5 -
55°C/50°C 98 79.3 60.9 42.8 24.6
DR30
35°C/30°C 30.6 - - - -
40°C/35°C 54.5 30.7 - - -
45°C/40°C 78 54.5 30.8 - -
50°C/45°C 101.4 77.8 54.4 30.9 -
55°C/50°C 124.9 101 77.5 54.3 30.9
DR35
35°C/30°C 34.8 - - - -
40°C/35°C 57.4 34.6 - - -
45°C/40°C 79.5 56.9 34.3 - -
50°C/45°C 101.4 78.7 56.4 34.1 -
55°C/50°C 123.3 100.4 77.9 55.9 33.9
DR40
35°C/30°C 42 - - - -
40°C/35°C 72 41.9 - - -
45°C/40°C 101.5 71.7 41.8 - -
50°C/45°C 130.8 101 71.4 41.8 -
55°C/50°C 160.2 130 100.3 71 41.6
DR45
35°C/30°C 44.6 - - - -
40°C/35°C 74.4 44.4 - - -
45°C/40°C 103.4 73.8 44.2 - -
50°C/45°C 132.3 102.5 73.2 43.9 -
55°C/50°C 161.2 131.1 101.6 72.6 43.6
DR50
35°C/30°C 53.1 - - - -
40°C/35°C 91.7 53.1 - - -
45°C/40°C 129.7 91.4 53. - -
50°C/45°C 167.6 129.2 91.1 53 -
55°C/50°C 205.5 166.8 128.6 90.8 52.9
(1) Output kW refers to the dry cooler heat rejection
