Kit Parts - Lower and Upper Aerofoils
Kit Parts - Base and Cover
Kit Parts - Outer and Inner Engine Nacelles
Kit Parts - Rear Cover and Upright Support
jet engine
4
Assembled kit
To operate the Jet Engine, press
the button to start the motor and
then rotate the lever handle to
increase or decrease the power to
the engine turbine blade assembly
Assembly sequence 67
Using a cross head screw
driver,tighten the bolt to secure the
cover plate to the base
29
