6. GentlyremovetheprotectionpaperfromthenewDialsurfaces.Faceup,slidetheDialoverthe
Adjustmentscrew,andallowittorestontheframeposts.AligntheDialmountingholestotheframe
posts. 
7. ScrewthetwoDialscrews(#2-56x1/4')in;Pressfirmlyintothescrewheadsandtwist.[Becareful
nottoovertorquethescrewandstriptheplasticthreads]. 
8. Attachtheneedleindicator.
a. Theneedleshouldbeasnugpress-fitontotherotor.If
theneedleeasilyslidesontotherotorandspinsfreely,
dothefollowing…
i. adhesiveisrequired:Non-permanent Thread-
Locker
,orNail-polish.
1. WithaTooth-pick,addaminuscule
dabofadhesive,to‘blob’therotortip.
Allowtheblobsetorget‘tacky’(3-4
minutes);avoidexcessthatwillrun
downtheshaftandinhibititfrom
turning.
2. PresstheneedleonfullyandrotateCCWonetime.
3. Removetheneedle.Reapplyasmallerblob.Waitanother4-5minutes.
b. Withtheneedlepointedtowards15MPH.Partiallystarttheneedleontotherotorshaft.
c. RotatetheneedleCCWuntilitispointedat7MPH.
d. Presstheneedlefullyontotheshaft,androtateCCWtillit'sEXACTLYcenteredon5MPH.
e. Standtheassemblyupright,level-flat,sogravitywon'tdrawtheneedleoff5MPH.
f. Allowtheadhesivetocurebeforeproceeding!!!.
g. ***Note:onlyifyouhaveconvenientaccessto12VDCPower,double-checktheneedle
registrationtothedial;seeRegistrationTestandFINETUNECalibrationaddendum.Thisis
donebeforecontinuingtheassemblyprocedure.

9. FeedtheBRN/BLU/BLKwiresthrutherubbergrommet.
10. FastentheFrame/Module/Dialassemblytothecase:
a. Alignthe‘leglesscorneroftheframeoverthegrommet,andslidetheassemblyintothecase.
b. Starteachframemountingscrewthruthecasebacksideandintoaframepost.Asrequired,
slightlyrotatetheframeassemblytoaligneachpostwithahole.
c. Withallthreescrewsinserted,presstheframeassemblysquarelyintothecasebottom,and
center.
d. Tightenthescrews.
11. Carefullycleanthedialfreeofany
fingerprintsorsmudges.

12. CleantheLensandLensgasket.

13. Placethegasketoverthecaseanddial.
(Notethecorrectorientationispictured
inDisassemblystep4.)

14. SliptheLensovertheAdjustment
screw,andintoplace.
15. SlidetheBezelbackon.

