Airo AC08MWS - Window Installation Methods; Sliding Window Installation Guide; Hung Window Installation Guide

Foam seal A
Foam seal B
Foam seal B
NOTE: Once the Vent Tube assembly and Adjustable Window Slider are prepared, choose from
one of the following two installation methods.
1. Cut Foam Seal A and B strips to the proper lengths and remove the adhesive backing. Attach them to
the window sash and frame as shown.
2. Insert the Window Slider assembly into the window opening.
3. Cut the non-adhesive Foam Seal C strip to match the width of the window. Insert the seal between the
glass and the window frame to prevent air and insects from getting into the room.
4. If desired, install the optional security bracket with 2 screws as shown.
5. Insert the tube Window Slider Adapter into the hole of the Window Slider.
window
installation 1
Method 1:
Sliding Window
Installation
OPTIONAL
Foam seal C
1 2
3 4
6
1. Cut Foam Seal A and B strips to the proper lengths and remove the adhesive backing. Attach
them to the window sash and frame as shown.
2. Insert the Window Slider assembly into the window opening.
3. Cut the non-adhesive Foam Seal C strip to match the width of the window. Insert the seal
between the glass and the window frame to prevent air and insects from getting into the room.
4. If desired, install the optional security bracket with 2 screws as shown.
5. Insert the tube Window Slider Adapter into the hole of the Window Slider.
Foam seal A
Foam seal B
Foam seal B
1
2
Foam seal C
3
OPTIONAL
4
window
installation 2
Method 2:
Hung Window
Installation
7
