AIRSYS UNICOOL 28V1B5 - Page 22

Installation
22
3.2.3 Summary Electrical Ratings (Wire Sizing)
Table 3-3 WPU Electrical Ratings
Model
Circuit #1
Circuit #2
AC/DC
48VDC
AC/DC
48VDC
MCA
MFS
MCA
MFS
MCA
MFS
MCA
MFS
7V1B2MR410AAC
29
30
--
--
--
--
--
--
7V1T2MR410AAC
29
30
--
--
--
--
--
--
7V1B2MR410ADC
27
30
--
--
6
10
--
--
7V1B2MR410ADC2
27
30
--
--
13
20
--
--
11V1B3MR410AAC
29
40
--
--
--
--
--
--
11V1B3MR410ADC
27
40
--
--
11
15
--
--
11V1T3MR410AAC
29
40
--
--
--
--
--
--
11V1T3MR410ADC
27
40
--
--
10
15
--
--
11V1B3MR410BAC
18
25
--
--
--
--
--
--
15V1T4MR410AAC
34
50
--
--
--
--
--
--
15V1B4MR410AAC
36
50
--
--
--
--
--
--
15V1B4MR410BAC
22
30
--
--
--
--
--
--
15V1B4MR410CAC
13
15
--
--
--
--
--
--
15V1B4MR410CACxxxD
18
25
--
--
--
--
--
--
28V2B5MR410AAC
36
50
--
--
29
40
--
--
28V1B5MR410BAC
24
25
--
--
44
50
--
--
28V1B5MR410BAC-SC
60
90
--
--
--
--
--
--
28V1B5MR410CAC
25
35
--
--
--
--
--
--
Note: Electrical Ratings are accurate at the time this document is produced. These ratings are always
superseded by the nameplate on the equipment.
Table 3-4 Controller Electrical Ratings
Model
Power Source
Max Power
Max Current
ASMUC.6
48VDC
50W
1.0A
ASMUC.6.DC
24VDC/48VDC
30W
1.3A/0.6A
ASMUC.6.AC
120VAC
90W
0.75A
