Installation
3.3 Physical Installation
To see unit dimensions, please consult Appendix C: Mechanical Drawings
3.3.1 Select the Wall for Installing the Unit
Select the wall where the unit will be installed. Be certain that the wall can support the weight of the unit and
that enough space is available for easy operation and installation, both inside and outside the mounting
location. Refer to Table 3-5 below for unit dimensions and weights by model number.
Table 3-5 Dimensions and Weight by Model Number
3.3.2 Clearances
The recommended clearances shown below should be adhered to when possible. Units will not be able to
operate correctly if minimum clearances are not met.
Note: The B5 cabinet requires a larger side clearance than other bottom supply units.
Table 3-6 Installation Clearances
Clearance between unit and
solid obstructions.
16 in (400 mm)
B5 Requires
24 in (600 mm)
8 in (200
mm)
B5 Requires
16 in (400
mm)
Also minimum spacing
between units
Recommended clearance
applies to complete
blockages in front of the
supply grille, minimum for
partial blockages
Enough space to allow
access to evaporator drain
tube.
NOT needed for B5 due to
support stand mounting.
Important. The wall selected for the unit must be strong enough to support both the static weight
of the unit and the vibration of a unit under operation.
