AIRSYS UniCool 7V1T2 - Page 103

Appendix A: Air Frame Drawing
103
Appendix A: Air Frame Drawing
Model
Frame
Type
Unit
A
B
7V1B2
Supply
mm
708
266
in
27 7/8
10 1/2
Return
mm
708
354
in
27 7/8
13 15/16
11V1B3
Supply
mm
760
266
in
29 15/16
10 1/2
Return
mm
760
354
in
29 15/16
13 15/16
11V1T3
Supply
mm
754
244
in
29 11/16
9 5/8
Return
mm
754
396
in
29 11/16
15 5/8
15V1B4
Supply
mm
878
266
in
34 9/16
10 1/2
Return
mm
878
354
in
34 9/16
13 15/16
15V1T4
Supply
mm
754
244
in
29 11/16
9 5/8
Return
mm
754
396
in
29 11/16
15 5/8
28V1B5
28V2B5
Supply
mm
998
240
in
39 5/16
9 7/16
Return
mm
998
310
in
39 5/16
12 3/16
Discharge
mm
998
210
in
39 5/16
8 1/4
