23
3AL Parts Lists
Refer to the relevant exploded view drawings for parts positioning.
3AL2041 Parts List
Position Quan. Description Material
1.01 1 Tank
1.02 1 Base [15.82W x 24.50L]
1.03.1 1 Side Cover
1.03.2 1 Top Cover
1.04 1 Front Cover
1.05 1 Radiator Cover
1.06 1 Baffle Cover
1.07 1 Frame
1.08 2 Baffle
1.09 2 Pump Mount [5.0W x 3.63H]
1.1 1 Baffle Cover Gasket
1.11 1 Level Switch Gasket
1.12 1 Level Switch Port Cover
1.13 1 Radiator Cooler
1.14 1 Level Switch
1.15 1 Solenoid Bracket
1.16 1 Fan Guard
2.01 1 Bulk Head Fitting (1/4"NPT) Brass
2.02 1 Instant Male Connector (1/4"NPTx1/4")
2.03 1 Instant Hose (1/4"OD)
2.04 2 Instant Fixed Elbow (1/8"NPTx1/4")
2.05 1 Water Purge Solenoid Valve-1/8" NPT, NC, 120VAC
2.07 1 Instant Hose (1/4"OD)
2.08 3 Instant Male Connector (3/8"NPTx1/4")
2.09 1 Purge Water Flow Control Valve (0.06GPM)
2.1 1 Instant Hose (1/4"OD)
2.11 1 Reducing Bushing (1"NPTx3/8"NPT) PVC
2.12 1 Tee (1") PVC
2.13 1 Inlet Check Valve 1"NPT) Stainless Steel
2.14 1 Street Elbow, 1"x 45º (Spig-Slip) PVC
2.15 1 Nipple (1") PVC
2.16 1 Street Elbow, 1" (Slip-Mipt) PVC
2.17 1 Threaded Adpt 1" (Spig-Fipt) PVC
2.21 1 Hose (1"ID) PVC
2.22 2 Hose Clamp (SAE-20) Stainless Steel
2.23 2 Elbow Connector (1"NPTx1") Nylon
2.24 2 Instant Swivel Elbow (1/4"NPTx3/8")
2.25 1 Instant Hose (3/8"OD)
2.26 1 Reducing Bushing (1"NPTx1/4"NPT) Galv.
2.27 1 Male Connector (1/2"NPTx5/8") Nylon
2.28 1 Hose (5/8"ID)-Vacuum Rated PVC
2.29 4 Hose Clamp (SAE-12) Stainless Steel
2.3 1 Hose (5/8"ID)-Vacuum Rated
2.31 1 Elbow Connector (1/4"NPTx5/8")
2.32 1 Anti Cavitation Relief Valve (1/4"NPT)
2.33 1 Plug (1"NPT)
2.34 2 Hex Head Plug (1/2"NPT) St.Stl.
2.35 1 Drum Plug (2"NPTx3/4"NPT)
2.36 1 Male Connector (3/4"NPTx1/2"OD)
2.37 1 Nipple (3/4"NPT)
2.38 1 Ball Valve (3/4"NPT)
2.39 1 Level Indicator (10"CC)
2.4 1 Cooling Fan (9" Dia. x 3 Blades)
2.41 1 Locking Bolt (M8 x 35mm)
2.42 1 Locking Bolt Washer
2.43 1 Vacuum Pump w/Motor (1.5HP,V30)
