3AL2341/3AL2430 Parts List
Pos. Quan. Description Material
1.01 1 Tank
1.02 1 Base [29.60W x 43.07L]
1.03.1 1 Side Cover
1.03.2 1 Top Cover
1.04 1 Front Cover
1.05 1 Radiator Cover
1.06 1 Baffle Cover
1.07 1 Frame
1.08 2 Baffle
1.09 2 Pump Mount [12.38W x 4.57H]
1.1 1 Baffle Cover Gasket
1.11 1 Level Switch Gasket
1.12 1 Level Switch Port Cover
1.13 1 Radiator Cooler
1.14 1 Level Switch
1.15 1 Solenoid Bracket
1.16 1 Fan Guard
2.01 1 Bulk Head Fitting (1/4"NPT) Brass
2.02 1 Instant Male Connector (1/4"NPTx1/4") Brass
2.03 1 Instant Hose (1/4"OD) Nylon
2.04 2 Instant Male Connector (1/8"NPTx1/4") Brass
2.05 1 Water Purge Solenoid Valve (1/8",NC,120V) Brass
2.07 1 Instant Hose (1/4"OD) Nylon
2.08 2 Instant Male Connector (3/8"NPTx1/4") Brass
2.09 1 Water Flow Control Valve (3/8"NPT,0.06 GPM)
2.1 1 Instant Hose (1/4"OD) Nylon
2.11 1 Instant Elbow Connector (1/2"NPTx1/4") Brass
2.12 1 Reducing Bushing (2-1/2 x 2 NPT) Nylon
2.13 1 Inlet Check Valve (2"NPT) Stainless Steel
2.14 1 Elbow Adapter (2"NPTx 2") CxM Brass (Cast)
2.15 1 Elbow (2") FxC Cooper (Wrot)
2.16 1 Fitting Adapter (2" x 2"NPT) Ftg x F Cooper (Wrot)
2.18 1 Reducing Bushing (2-1/2 x 2 NPT) Nylon
2.19 1 Elbow Connector (2"NPT x 2") Nylon
2.21 1 Hose (2"ID) PVC
2.22 2 Hose Clamp (SAE-32) Stainless Steel
2.23 1 Elbow Connector (2"NPT x 2") Nylon
2.24 2 Instant Swivel Elbow (1/4"NPT x 3/8")
2.25 1 Instant Hose (3/8"OD)
2.26 1 Reducing Bushing (2"NPTx1/4"NPT) Galv.
2.27 1 Elbow Connector (1"NPT x 3/4") Nylon
2.28 1 Hose (3/4"ID)-Vacuum Rated PVC
2.29 4 Hose Clamp (SAE-12)St. Stl.
2.3 1 Hose (3/4"ID)-Vacuum Rated
2.31 1 Elbow Connector (1"NPT x 3/4") Nylon
2.32.2 1 Elbow Connector (1/2"NPTx3/8") PVC
2.32.3 1 Hose (3/8"ID)-Vacuum Rated Nylon
2.32.4 2 Hose Clamp (SAE-6)St. Stl.
2.32.5 1 Elbow Connector (1/2"NPTx3/8")
2.33 1 Plug (1"NPT) Nylon
2.34 2 Hex Head Plug (1/2"NPT) PVC
2.35 1 Drum Plug (2"NPTx3/4"NPT) Stainless Steel
2.36 1 Male Connector (3/4"NPTx1/2"OD)
2.37 1 Nipple (3/4"NPT) Brass
2.38 1 Ball Valve (3/4"NPT) Brass
2.39 1 Level Indicator (10"CC) Brass
2.4 1 Cooling Fan (16" Dia. x 8 Blades)
2.41 1 Locking Bolt (M10 x 40mm)
2.42 1 Locking Bolt Washer
2.43 1 Vacuum Pump w/Motor (15HP,V330)
