L160, L230 DESCRIPTIONS
Pos. No.
L160, L230
Pos. No.
L160, L230
Pos. No.
L160, L230
159
Exhaust valve ass'y
317
Set screw
425
Rubber foot support
159-1
Exhaust valve fixed bolt
321
Pump shaft end fan
430
Name plate
159-2
Exhaust valve washer
326
Washer
431
Directional Arrow
159-3
Exhaust valve spring
327
Hexagon head screw
474
Air filter
159-4
Exhaust valve plate
330
Hexagon nut
476
Ball valve
159-5
Exhaust valve lock nut
331
Washer
490
Gasket Kit
159-6
Exhaust valve seat plate
332
Exhaust filter cover
500
Maintenance Kit
185
Cylinder gasket
333
Hexagon nut
600
Motor(NEMA)
189
Allen bolt
334
Washer
600.3
Motor Fan(NEMA)
202
O- ring
335
Separator valve stud
600.4
Motor Fan Cover(NEMA)
203
Locking screw
336
Separator valve spring
601
Hexagon head screw(NEMA)
218
Socket
337
Flat spring
602
Spring lock washer(NEMA)
230
Oil tube(A)
338
Separator valve flat-ring
613
Coupling, Motor side(NEMA)
231
Oil tube(B)
339
Separator valve support
630
Motor Mounting Bracket(NEMA)
243
Gas ballast o-ring
340
Fan food
244
Ball guide
341
Allen bolt
245
Ball
342
Cover holder
246
Ball guide o-ring
350
Hexagon nut
247
End plate o-ring for gas ballast
351
Stud
251
Check valve plate
352
Adjusting ring
252
Check valve guide
353
Deminster spring
253
Check valve plate flat-ring
354
Demister cover
254
Check valve spring
355
Hexagon nut
255
Inlet part o-ring
356
Set screw
