AirTech L12 - Page 25

256
Hexagon nut
360
Hexagon nut
257
Check valve plate stud
361
Washer
258
Distance bushing
362
Connecting bolt
259
O- ring
365
Hexagon head screw
260
Inlet flange
366
Float
261
Inlet screen
367
Float valve nozzle
265
Allen bolt
369
Hexagon nut
275
Hollow-core screw
390
Adapter for eye bolt
283
Hollow-core screw
391
Eye bolt
285
Hollow-core screw
400
Motor
288
Sealing ring
400.3
Motor Fan
300
Motor Mounting Bracket (IEC)
400.4
Motor Fan Cover
301
Allen bolt
401
Hexagon head screw
302
Spring lock washer
402
Spring lock washer
311
Coupling, pump side
417
Slotted set screw
313
Coupling, Motor side
421
Rubber foot
316
Set screw
424
Rubber foot support
