1. PREFACE
This manual is designed to provide you with important service information. Be sure to read the safety precautions
prior to servicing the unit.
1.1 Safety Precautions
1 When servicing, set the POWER of the CONTROL PANEL to OFF and unplug the power cord.
2 Observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
3 After servicing, make an insulation resistance test to prevent the customer’s exposure to shock hazards.
1.2 Insulation Resistance Test
1 Unplug the power cord and connect a jumper between 2 pins.
2 The grounding conductor (green or green & yellow) is to be open.
3 Measure the resistance value with an ohm meter between the jumper lead and each exposed metallic part on
the equipment at all MODES (except POWER OFF).
4 The value should be over 1 MΩ.
1.3 Specifications
MODELS
ITEMS
PCMH45
Power Supply 220-240V, 50Hz
Input (W) 70W
Running Current (A) 0.3A
Fan Type Fan Blade
Fan Speeds 3 (Hi/Med/Lo)
Operation Control Control Panel
Air Direction Control Horizontal Louver (Up & Down) - Manual
Timer Control 2 to 8 hours
Protector Fan Motor Internal Thermal Protector
Power Cord 1.8m (3 wire with grounding)
Water Fill System Manual (from top panel)
Auto (from tap water connector)
Drain System Manual empty water reservior
Evaporating Capacity 45 L/24h (at 21°C x 30% RH)
Water Tank Capacity 7.9 US Gallon / 30 L
Net Weight 27.3 lbs / 12.4 kg
Outer Dimension
(W x D x H)
29.5’’ x 17.3” x 29.3”
750 x 440 x 745 mm
