AIRTRONICS D2 - Page 2

REVISION LEVEL A - 09/09/15
TABLE OF CONTENTS
Chapter Content Page
System Overview ................................................................................................3
Diagnostic Devices ..............................................................................................4
Visual Inspection . . . . . . . . ........................................................................................6
Maintenance / Troubleshooting & Repair .............................................................................11
Service Information .............................................................................................19
Parts Breakdown . . . . . . . . .......................................................................................26
Fuel Filter / Fuel Pump Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Ducting Rating Guide . . . . . .......................................................................................33
The EW14 Warranty Process requires Edith extraction printouts to record codes before proceeding with repairs – and after the repair
steps listed in this manual are completed. For your warranty claim to be paid you must document the Complaint, Cause and Correction steps in your
warranty claim write-up.
CAUTION: Indicates that personal injury or damage to equipment may occur unless specic guidelines are followed.
DANGER: Indicates that serious or fatal injury may result if specic guidelines are not followed.
This document aims to support service technicians and end users in North America. This does not replace documentation produced by J. Eberspächer.
The installation instructions and standards described in this document are NOT APPLICABLE TO MARINE INSTALLATIONS.
Please consult a certied Espar Marine dealer for marine installation.
This publication was correct at the time of going to print. However, Espar Inc. has a policy of continuous improvement and reserves the right to amend any
specications without prior notice.
2
PLEASE NOTE!
4
5
1
2
3
6
7
8
