AIRTRONICS D2 - Page 9

Return/inlet air must be
clear from obstructions
Outlet air must be
clear from obstructions
Return/inlet air must be
clear from obstructions
3
REVISION LEVEL A - 09/09/15
9
VISUAL INSPECTION
Return air must be clear from obstructions. If the carpet is too close, cut away from the inlet of the Espar heater to allow for more clearance. Outlet air must
be clear from obstructions.
Figure 14
Figure 15
PLEASE NOTE!
