14-10
EXPLODED VIEWS AND SPARE PARTS LISTS
SM FLODCI 2-A.4 GB
14.10 Indoor Unit: FLO 30 DCI
Item No. Part No. Description Qty
1 4525902 GRILLE ASSY 1
2 4523299 FILTER 1
3 4523303 SHAFT LOCKER 2
4 4518113 AIR FILTER ASSY 1
5 4525610 FRAME ASSY 1
6 4523301 SCREW COVER 3
7 4523302 FIX LOCKER 4
8 462350007 EVAPORATOR ASSY FLO80 R410A 1
9 4525112 DISPLAY ASSY. 901-255-30 1
10 4525612 AIR OUTLET ASSY 1
11 4524962 TEP MOTOR B 2
12 4524965 STEP MOTOR WIRE A 1
13 4518664 DRAIN HOSE 1
14 4516204 BEARING ASSY.,FAN 1
14 4524954 CROSS FAN 1
16 4525611 REAR PANEL ASSY 1
17 433133 IONIZER DISPLAY 1
18 4523306 IONIZER COVER(NO IONIZER) 1
4523307 IONIZER WIRE COVER(WITH IONIZER) 1
19 4524967 IONIZER WIRE A 1
20 4523372 FLO-30 INSTALLATION PLATE 1
21 4523309 TUBE OUTLET 1
22 4525111 REMOTE CONTROL BOX 974-700-00 1
23 433134 IONIZER POWER 1
24 453109300 IONIZER CABLE B 1
25 4523311 MOTOR HOUSING 1
26 4524953 FAN MOTOR 1
27 4523313 MOTOR WATER BREAKER 1
28 4523312 MOTOR COVER 1
29 4524661 FIX PLATE 1
30 4524961 STEP MOTOR A 1
31 4524966 STEP MOTOR WIRE B 1
32 4523308 WATER BREAKER COVER 1
33 4525113 POWER CORD CABLE(optional) 1
34 438082 THERMISTOR INDOOR COIL BACK 1
35 4519813 THERMISTOR ROOM BLACK 1
36 4525831 WIRE TUBE 1
37 453161200 CONTROL BOX 916-514-00 1
38 4516263 SENSOR BASE 1
39 4524963 ESF (optional) 1
40 4523304 WIRING COVER 1
41 4523300 FILTER R 1
