14-6
EXPLODED VIEWS AND SPARE PARTS LISTS
SM FLODCI 2-A.4 GB
14.6 Outdoor Unit: GC 21
Item No. Part No. Description Qty
1 4517144 FAN COVER PP+UV 1
2 452795700 PAINTED LEFT CABINET ASSY 1
3 4521642 Painted Right Cabinet and Isolation Assy. 1
4 4523141 M10 Hexagon locked nut M10 1
5 4526841 cusion for fan 1
6 4526510 FAN D=460mm (3 blade) 1
7 453026500 DC Motor SIC-71FW-F170-2 1
8 453036400 Motor Support 1
9 453238900 Sensor/OAT 1
10 4526775 Compressor top thermistor(CTT) 1
11 4526776 Outdoor coil thermistor(OCT) 1
12 453035800 Partition Plate 1
13 453036100 Base Plate Paint Assy. 1
14 4526221 Compressor wire 1
14 453041900 Liquid Accumulator 1
16 452882900 Condenser and distributor welding assy. 1
17 4523446 Scroll DC compressor assy. 5CS130XCC03 1
18 453034000 4-way Valve System Assy. 1
19 4522509 4-Way valve coil 1
20 4516766 PAINTED VALVE PLATE ASSY 1
21 4526301 High pressure stop valve R410a 1
22 4524595 1/2” Gas Valve for ONG R410A 1
23 4526214 Electronic expansion valve ZDPF(L)-1.6C-01-RK for R410A 1
24 4526216 EEV COIL QA(L)12-MD-02 1
25 4518952 4-W valve SHF-7H for R410A 1
26 4525938 PAINTED RIGHT-BACK CABINET ASSY 1
27 4523145 R.lifter 1
28 4517028 PAINTED LEFT-BACK GRILL 1
29 4516758 SMALL HANDLE 1
30 452841100 Earth wire 3
31 453238800 Ground Wire 1
32 453238700 Wire UL1007 16AWG/COM 1
33 4519188 4 poles terminal block 1
34 453238600 Wire 1014 16#/Power Input 1
35 204107 Cable clip Nylon 1
36 453048500 DCI 2.8kW EMI Filter Board 901-107-00 1
37 453052900 Therminal Plate Assy. 1
38 4526585 connect for motor backet 1
39 453030500 Outdoor DCI Controller/2.8kW(English) 906-105-00 1
40 4516788 PAINTED TOP COVER ASSY 1
