EXPLODED VIEWS AND SPARE PARTS LISTS
SM FLODCI 2-A.4 GB
14.8 Indoor Unit: FLO 24 DCI
Item No. Part No. Description Qty.
1 452917400 Grille 1
2 452919800 Air Filter 1
3 4518113 Active Carrbon(Cold Catalyst) Filter 1
4 465720009 Frame Asy 1
5 452919600 Screw Cover 1
6 453260400 Evaporator Assy 1
7 4522754 Draining Hose 1
8 453053900 Air Outlet Assy 1
9 452917500 Flap 1
9 452917600 Flap 1
10 452930700 Vert. Louver 1
10 452918200 Vert. Louver 1
11 4518662 Bearing Assy 1
12 453024900 Cross Flow Fan 1
13 453053800 Base Assy 1
14 452920100 Installation Plate 1
14 452919400 Tube Bracket 1
16 453206800 Motor 1
17 452918800 Motor Cover 1
18 453050200 Step Motor 1
18 453050300 Step Motor 1
19 Power Wire 1
20 4519147 Cable locker 1
21 453080400 Display 1
22 452919100 Sensor 1
23 453207000 Control Box Assy 1
24 438082 Thermistor indoor coil 1
25 4519813 Thermistor Room 1
26 452919500 Terminal Cover 1
27 4524963 Electrostatic Filter/Filter Frame (Optional) 1
29 453042500 Remote control 1
30 4518651 Motor Side Cover 1
31 4526946 LCD Display Lens Assy 1
32 453057900 Gear Box Assy 1
33 452918700 Louver Support 1
35 4518657 Tube Lock 1
37 4524967 Ionizer Cable (Optional) 1
38 433134 Ionizer Power(Optional) 1
39 433133 Ionizer Cover/Ionizer Unit(Optional) 1
